Fundamentals of geometrical dimensioning and tolerancing (ISO & ASME) - ONLINE & FACE-TO-FACE DELIVERY OPTIONS

Fundamentals of geometrical dimensioning and tolerancing (ISO & ASME) - ONLINE & FACE-TO-FACE DELIVERY OPTIONS

  • 1,22000 (includes shipping and handling)

All prices are in AUD and exclusive of GST

IMPORTANT INFORMATION FOR NSW BUSINESSES
As an Investment NSW’s Boosting Business Innovation Program partner, NMI may be able to offer NSW businesses a subsidy of 75% of the course value, up to a maximum of $1,100 per participant, for up to 4 participants from one business.
Contact training@measurement.gov.au for more details PRIOR TO enrolling. Other conditions apply.

Please note, a tax invoice will automatically be emailed to you after the credit card payment goes through. If you don't receive it, check your Junk inbox. Do not tick the tax invoice button if paying by credit card. For those who require an invoice to make a payment, please choose the relevant option after checkout.

Fundamentals of GD&T (based on ISO standards)

This course provides information on ISO 1101 Geometrical Product Specifications, related standards and their application to engineering drawings. Please find the link to the brochure here.

Knowledge and skills

The course will provide you with the knowledge and skills to:

  • recognise the ISO 1101 drawing practices and benefits of geometrical tolerancing
  • understand key geometrical tolerancing concepts
  • interpret datum reference frame and select datum features
  • know symbols and how to apply them to drawings

Fundamentals of GD&T (based on ASME Y14.5-2009 standard)

This course is based on ASME Y14.5-2009 standard. You will learn about the symbols, modifiers, rules and concepts of geometric dimensioning and tolerancing (GD&T). Please find the link to the brochure here.

Knowledge and skills

The course will provide you with the knowledge and skills to:

  • understand the benefits of geometric tolerancing
  • know GD&T symbols and how to apply them to drawing
  • interpret datum reference frame and select datum features
  • recognise when a specification is incomplete or incorrect

ONLINE session times (delivered over 2 days, 2 sessions per day):

Session 1: 09:00-12:30, session 2: 13:00-16:30

Topics

The topics covered on both courses include:

  • engineering drawing conventions
  • general symbols and terms
  • rules and concepts of GD&T
  • the datum system
  • form controls
  • orientation controls
  • tolerance of position
  • runout controls
  • profile controls

Past Attendees have said...

"This course will enable us to take a new look at our vehicle designs and make modifications that will give a good chance of reputable product being manufactured"

"This course will allow better communication between our design engineers, manufacturing & quality inspectors "

Further information

Online training resources will be provided electronically.

Face to face courses are suspended until further notice.

For more information contact +61 2 8467 3796 or training@measurement.gov.au.
